| Thermal Module | |
| Image Sensor | Vanadium Oxide Uncooled Focal Plane Arrays |
| Resolution | 160 × 120 (the resolution of output image is 640 × 480) |
| Pixel Interval | 17μm |
| Response Waveband | 8μm to 14μm |
| NETD | less than 40 mk (@25°C, F#=1.1) |
| Lens (Focal Length) | 3.1 mm |
| IFOV | 5.48 mrad |
| Field of View | 50° × 37.2° (H × V) |
| Min. Focusing Distance | 0.15 m |
| Aperture | F 1.1 |
| Optical Module | |
| Image Sensor | 1/5” Progressive Scan CMOS |
| Image Resolution | Configurable: 800 × 600, 1600 × 1200 |
| Shutter Speed | 1/30 s to 1/100,000 s |
| Lens (Focal Length) | 2 mm |
| Field of View | 92.6° × 75.8° (H × V) |
| Compression Standard | |
| Video Compression | Main stream: H.265+/H.265/H.264+/ H.264 Sub stream: H.265/H.264/MJPEG |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| Video Bit Rate | 256 Kbps to 16 Mbps |
| Smart Feature | |
| Temperature Range | 30°C to 45°C (86°F to 113°F) |
| Temperature accuracy | ±0.5 °C |
| Temperature measurement type | 3 temperature measurement rule types, 21 rules |
| Image | |
| Main Stream | Thermal channel: 25fps (640 × 480) Optical channel: 25fps (800 × 600, 1600 × 1200)) |
| Sub Stream | Thermal channel: 25fps (640 × 480) Optical channel: 25fps (800 × 600, 1600 × 1200) |
| Image Enhancement | 3D DNR |
| Image Setting | Brightness, Contrast, Background Correction, Manual Correction |
| Fusion | Support (Thermal View and Optical View Combined) |
| Network | |
| Alarm Trigger | Video tampering alarm, Network disconnected, IP address conflict, Illegal login, HDD full, HDD error |
| Alarm Action | Upload to SD card/FTP/NAS, notify surveillance center, smart capture, video recording, email linkage, audio alarm, white light alarm |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| General Function | One-key reset, heartbeat, mirror, password protection, IP address filter |
| Interface | |
| Communication Interface | 1 RJ45 Ethernet port, 1 RS-485 interface |
| Alarm | 1 input, 1 output |
| General | |
| Menu language | English |
| Power Supply | 10-30 VDC, Max. 5W PoE (802.3af, class 2) |
| Working Temperature and Humidity | -20 °C to 50 °C (-4 °F to 122 °F), humidity less than 95% |
| Protection | IP 67 |
